drylin® E stepper motor with Connector, encoder and brake, NEMA 17

  • Installation size: NEMA 17 / flange dimension 42 mm
  • Protection class: Motor housing IP65 (shaft sealing IP52)
  • Holding torque: 0.50 Nm
  • Nominal current: 1.80 A
  • Motor connections: Metric M8/M12 connectors
  • Brake voltage: 24V
  • Integrated brake for vertical loads
Product description
NEMA17: Small, but lots of power

This little motor has impressive torque and high RPMs. Reliable operation with quick movements of low loads.

Stepper motors from igus® are a good supplement to drylin® linear axes. They are characterised by their cost-effectiveness, their precision and easy control. They work reliably under the most varied environmental conditions (depending on the selected class of protection IP). The igus® stepper motors can be connected to the most common motor controls using standardised electrical connection.

The encoder sends signals from the motor to the motor control. The encoder verifies that the required linear motion has occurred precisely as required. Encoder = increased machine accuracy.

The brake can hold the payload in position when the motor is not under power. This is used as a safety feature during power failures – strongly recommended for vertically mounted systems.
