Small linear systems
Miniature linear axis for the smallest installation spaces
drylin® SLN linear axes offer the solution for tight installation spaces. The small axis measures 28x22mm and is configurable with a stroke length of up to 250mm.
Thanks to the lubrication-free polymer sliders, it operates extremely quietly and is also very lightweight. The micrometre table of installation size 27 forms the basis. The lead screw axis is available with ball bearings in the shaft end supports.
The drylin® SLN micrometre table can be adjusted both manually via hand wheel and motorised combined with drylin® E stepper and DC motors.
Linear systems for small installation spaces
Miniature linear axis SLN without motor
SLN-27-03 Entry-level model with basic carriage made of igus® polymer
SLN-27-04 Carriage with manual clearance and height adjustment
SLN-27-05 Carriage with axial spring preload and manual clearance and height adjustment
SLN-27-14 Carriage with manual clearance and height adjustment, lead screw with ball bearings
SLN-27-15 Carriage with axial spring preload and manual clearance and height adjustment, lead screw with ball bearings
Areas of application: Feed movements with lightweight, sensor adjustments, light handling tasks in equipment and laboratory technology.
Linear system accessories - control elements
- Accessories for manual positioning and format adjustment
- Assembly and fastening options
- Stepper and DC motors for electrical drive
The correct motor alignment for the lead screw axis
In our instructions you will find out which alignment of the electrical connections for e.g.motor, encoder or brake connection is best suited for the lead screw axis.
We define the alignment in degrees (looking at the motor from behind).
