Cartesian robot - drylin® gantry robots

A maintenance-free, low-cost automation solution

igus® cartesian robots are motor driven systems available as a flat, line or room gantry. igus® gantry robots can be bespoke in design for a host of automated tasks in a multitude of industries, performing xyz linear motions. Typical applications for these linear robots are pick and place, sorting, labelling and an array of assembly applications. The cartesian robot are engineered to be quiet and smooth in operation with self-lubricating components that are corrosion and maintenance-free.

Additionally, igus® cartesian robots are supplied with the igus® drylin® linear modules along with a NEMA stepper motors for each axis

Would you like more information about gantries or do you need an individual consultation? Our experts will be happy to get in touch with you.

Contact an expert

igus® gantries - cartesian robot types

Room gantries

For xyz movements

Loads up to 5kg
Precision requirements up to approx. 0.8mm
Speeds up to max. 0.5m/s

Visit the shop

Line gantries

For movement in one direction

For loads up to 5kg
For precision requirements up to approx. 0.2mm
For speeds up to max. 1m/s

Visit the shop

Flat gantries

For xy movements

Load capacity up to 80N
Precision requirements of up to approx. 0.5mm
Speeds of up to 1.5m/s

Visit the shop

robot control software for linear robots

igus® Robot Control software

Intuitive robot programming, simulation and control system

Make your automation solution ready for use with igus® Robot Control. Due to the modular design, different robot kinematics can be controlled, for example, delta robots, linear robots and multi-axis joint robots.
You can now download and test the software for free.

Find out more

We use these products for our cartesian robots

Linear axes

with toothed belt drive
with lead screw drive
Lightweight cantilever axis

Overview of linear axes

Motors

NEMA stepper motors
Direct-current motor (DC)
EC/BLDC motors

Overview of motors

Motor control and accessories

Motor control systems, motor flanges, couplings
Initiators and proximity switches
External brake resistors

Overview of motor control systems

Complete the system and protect your cables

Thanks to the wide range of energy chain systems, we are able to provide a complete gantry system with cables and cable carriers.

This ensures the linear movement has an uninterupted movement and protected energy cables.

For the full energy chain overview click here

Visit the shop

Low Cost Automation education program

The Low Cost Automation education program gives you an insight into the programming of your linear robot with the free "igus Robot Control" software, so that your automation project gets off to a smooth start.

Go to education program
