Microphone Cable Reel e-spool®: Compact & Reliable

Innovative cable management for single and stereo microphone setups

The e-spool® microphone cable reel closes a gap in sound technology by combining compact size and lightweight design with exceptional versatility. Its innovative twisterband system eliminates the need for a slip ring, ensuring uninterrupted sound transmission over an extension length of up to 30 meters.


Available in two configurations:

  • Single-cable version for one microphone
  • Stereo version with two cables for connecting two microphones
    Both systems include a motor and control unit, while the stereo version features an additional microphone rail for dual setups.
Shop NowContact an Expert
Shop Energy ChainsShop chainflex CablesDownload our BrochurelaunchConfigurator

e-spool® microphone stereo

microphone cable reel stereo

Our well-known e-spool® microphone gets a variant that enables the guidance of two shielded special cables. The e-spool microphone stereo therefore offers a connection for two microphones.

Request e-spool microphone stereo now
e-spool® microphone cable reel mono

Our e-spool® microphone is designed to support the guidance of a single shielded special cable. As a result, the e-spool microphone mono provides a dedicated connection for one microphone.

Request e-spool microphone mono now
Tech up triangle

Tech up

  • Best audio quality without cable interruption/slip ring
  • No cable interruption as there is no slip ring
  • Different media and diameters possible in one drum
  • Can be adapted to technological developments thanks to simple replacement of the cables in use
  • No manual work at height
  • Space-saving, as the cable is reeled up in the starting position
Cost down triangle

Cost down

  • No additional support required for the microphone
  • Low use of raw materials as no slip ring and less copper
  • No additional copper components in the system (except for copper conductors)
  • No need to replace/maintain contact points or sliding contacts
Proof square

Proof

  • twisterband successfully used as a slip ring alternative in hundreds of e-spool® applications
  • Fulfils the requirements of DIN EN17206 and DGUV Principle 315-390
  • Individually designed and tested system
Sustainability circle

Sustainability

  • Replacement/maintenance of contact points or sliding contact is not required
  • Have your energy or drag chain recycled at the end of its life cycle at igus chainge. You will receive a voucher, irrespective of the manufacturer.
e-spool® microphone cable reel drawing

Microphone cable reel technical details:

  • Max. speed: 0.4m/s
  • Max. acceleration: 0.4m/s²
  • Temperature range: +10°C to +50°C
  • Max. cable diameter: 8.5mm
  • Equipment: special XLR cable 2x(2x0.14mm²)C
  • Not included in the scope of delivery: microphone, connector

Operating Environment

Optimised for indoor use. For outdoor applications, the system must be protected against wind and weather.
