Plain bearings in heavy-duty applications

In comparison: lubricated metal bearings and self-lubricating igutex® plain bearings

Force/load:
80 MPa (12.8 t on a plain bearing with Ø 40 mm, length 40 mm)

Speed:
0.01 m/s (30 cycles 50°/min.)

shaft:
42 CroMo4+QT gas nitrocarburised with post-oxidation

Cycles:
50,000 = 1.75 km running performance

Steel bearing 16MnCr5, hardened

• Lubricated every 4 hours (unloaded condition)
• Breakage after approx. 10,000 cycles
• Massive shaft wear

Bronze bearing

• Lubricated every 4 hours (unloaded condition)
• Breakage after approx. 10,000 cycles
• Massive bearing wear

Metal-polymer bearing

• Lubricated every 4 hours (unloaded condition)
• 50,000 cycles achieved
• Massive bearing and shaft wear

igus igutex TX1 plain bearing

• Tested in dry operation
• 50,000 cycles achieved
• Low wear
• Best result in the test

Kässbohrer Geländefahrzeug AG

In the chassis of its tracked vehicles, Kässbohrer Geländefahrzeug AG uses igutex® fibre composite bearings that function reliably even in dirt.

Demarko

Demarko uses igutex® fibre composite bearings in oscillating axles for semi-trailers. The bearings are part of the igus® standard range and require no additional lubrication.

Ship & Yacht Engineering Ltd.

The Ship & Yacht Engineering Ltd. stern gallows is suitable for a swivel load of up to 20 tons and uses igutex plain bearings in the swivel kinematics because they also work in weather and salt water.

Thaler GmbH & Co. KG

iglidur plain bearings can also be found in Thaler GmbH & Co. KG farm loaders, where they are used because the bearing points are resistant to dirt and require little maintenance.
