| Part No. | z | Module | D | Tooth width |
|---|---|---|---|---|
| PRT04-50-TO-ST | 118 | 1 | 120 | 1 |
| PRT04-60-TO-ST | 128 | 1 | 130 | 1 |
| PRT04-100-TO-ST | 168 | 1 | 170 | 1 |
| PRT04-150-TO-ST | 218 | 1 | 220 | 1 |
| PRT04-200-TO-ST | 268 | 1 | 270 | 1 |
| PRT04-300-TO-ST | 368 | 1 | 370 | 1 |
| Part No. | z | Module | D | Tooth width |
|---|---|---|---|---|
| PRT-04-50-TO-AT10 | 38 | ? | 118.9 | 1 |
| PRT-04-60-TO-AT10 | 42 | 131.7 | 1 | |
| PRT-04-100-TO-AT10 | 54 | 169.9 | 1 | |
| PRT-04-150-TO-AT10 | 70 | 220.8 | 1 | |
| PRT-04-200-TO-AT10 | 86 | 271.7 | 1 | |
| PRT-04-300-TO-AT10 | 117 | 370.4 | 1 |
| Part No. | z | Module | D | Tooth width |
|---|---|---|---|---|
| PRT-04-50-TO-HTD5M | 76 | ? | 120 | 1 |
| PRT-04-60-TO-HTD5M | 83 | 131 | 1 | |
| PRT-04-100-TO-HTD5M | 108 | 170.9 | 1 | |
| PRT-04-150-TO-HTD5M | 140 | 221.8 | 1 | |
| PRT-04-200-TO-HTD5M | 171 | 271.2 | 1 | |
| PRT-04-300-TO-HTD5M | 234 | 371.4 | 1 |
✅ Select the right module
✅ What to consider when it comes to spacing
✅ The correct tooth width
✅ This is how the part number reveals the suitable product
✅ These forces are possible
✅ Use motors
